MICROSMDCH010F-02

MICROSMDCH010F-02

Manufacturer Part MICROSMDCH010F-02
Manufacturer Littelfuse Inc.
Description PTC RESET FUSE 30V 100MA 1210
Category Circuit Protection
RoHS Lead free / RoHS Compliant
Warranty 365 days
Datasheet -
GB-T-27922
ISO-9001-2015
ISO-13485
ISO-14001
ISO-28000-2007
ISO-45001-2018
Product Attributes
Type Description
Product Status:Active
Type:Polymeric
Voltage - Max:30V
Current - Max:10 A
Current - Hold (Ih) (Max):100 mA
Current - Trip (It):350 mA
Time to Trip:100 ms
Resistance - Initial (Ri) (Min):1.2 Ohms
Resistance - Post Trip (R1) (Max):11 Ohms
Resistance - 25°C (Typ):-
Operating Temperature:-40°C ~ 125°C
Ratings:-
Mounting Type:Surface Mount
Package / Case:1210 (3225 Metric), Concave
Size / Dimension:0.127" L x 0.102" W (3.22mm x 2.58mm)
Height - Seated (Max):-
Thickness (Max):0.038" (0.97mm)
Lead Spacing:-
