4N40

4N40

Manufacturer Part 4N40
Manufacturer onsemi
Description OPTOISOLATOR 5.3KV SCR 6DIP
Category Isolators
RoHS Lead free / RoHS Compliant
Warranty 365 days
Datasheet -
GB-T-27922
ISO-9001-2015
ISO-13485
ISO-14001
ISO-28000-2007
ISO-45001-2018
Product Attributes
Type Description
Product Status:Obsolete
Output Type:SCR
Zero Crossing Circuit:No
Number of Channels:1
Voltage - Isolation:5300Vrms
Voltage - Off State:400 V
Static dV/dt (Min):500V/µs
Current - LED Trigger (Ift) (Max):14mA
Current - On State (It (RMS)) (Max):300 mA
Current - Hold (Ih):1mA
Turn On Time:50µs (Max)
Voltage - Forward (Vf) (Typ):1.1V
Current - DC Forward (If) (Max):60 mA
Operating Temperature:-55°C ~ 100°C
Mounting Type:Through Hole
Package / Case:6-DIP (0.300", 7.62mm)
Supplier Device Package:6-DIP
Approval Agency:UR
