HFW10S-2STE1LF
| Manufacturer Part | HFW10S-2STE1LF |
|---|---|
| Manufacturer | Amphenol ICC (FCI) |
| Description | CONN FFC FPC VERT 10POS 1MM SMD |
| Category | Connectors, Interconnects |
| RoHS | Lead free / RoHS Compliant |
| Warranty | 365 days |
| Datasheet | - |
Product Attributes
| Type | Description |
|---|---|
| Product Status: | Obsolete |
| Flat Flex Type: | FFC, FPC |
| Mounting Type: | Surface Mount |
| Connector/Contact Type: | Contacts, Vertical - 1 Sided |
| Number of Positions: | 10 |
| Pitch: | 0.039" (1.00mm) |
| Termination: | Solder |
| FFC, FCB Thickness: | 0.30mm, 0.33mm |
| Height Above Board: | 0.209" (5.30mm) |
| Locking Feature: | - |
| Cable End Type: | Straight, Tapered |
| Contact Material: | Phosphor Bronze |
| Contact Finish: | Tin |
| Housing Material: | Polyamide (PA6T), Nylon 6T, Glass Filled |
| Actuator Material: | - |
| Features: | - |
| Voltage Rating: | 100V |
| Operating Temperature: | -55°C ~ 85°C |
| Material Flammability Rating: | UL94 V-0 |
